Hidrante bajo nivel de tierra LLOBREGAT SIMPLE DN100

Ref	A	B	H	ØC	ØD
HIDN100	500	297	298	Ø220	Ø154

Description

Underground hydrant to be installed. May include the disposal unit and cover for installation (depending on model).

The hydrant is a device that supplies a large amount of water in a short amount of time.

It allows the connection of hoses and firefighting equipment, as well as the filling of firefighters' water tanks.

Designed for space issues, such as on sidewalks in large cities. By remaining underground, the risk of frost damage is minimal.

Horizontal or vertical DN-100 connection

Outlet: 100mm aluminium or bronze fitting, Barcelona model

Optional 70mm aluminum fitting

Nominal pressure of 16 bar

Sealing test of 25 bar

Interior components highly resistant to corrosion and aging (brass and stainless steel)

Cast iron disposal iron and cover
