Luminaire Vialia Evo
ILVE
X Product added successfully to your WISHLIST. If you want to see all the products click here.
Description
Classic residential luminaire ideal for urban residential areas (roads, squares, green spaces...). Compact profile and internal LED cooling system. Mounting by means of a ball joint system, vertical fixing bracket or suspended. Power up to 100W thanks to its high dissipation capacity. High resistance and reliability. Ready for any intelligent lighting control solutions.
MAIN FEATURES:
High efficiency. Up to 142 lm/W real
Easy opening without tools
18 different light distributions
Zhaga Standard (Book 15)
Ready 4IoT. Ready for connectivity
APPLICATIONS:
Urban Roads and Streets
Residentials Streets (Zones 30)
Cycle Lane and Narrow Tracks
Rural Roads
Parking
See more… Success stories that inspire
Other products of the family
| Real luminous flux (T) =85ºC) | Initial luminous flux (T) =25ºC) |
| REF. | Nº LEDs | Power W | I Driver mA | Flux lm | Efficacy lm/W | Flux lm | Efficacy lm/W |
| Vialia Evo | ILVE60 | 16 | 20 | 375 | 2842 | 142 | 3240 | 162 |
| 16 | 40 | 750 | 5642 | 141 | 6432 | 161 |
| 16 | 60 | 1125 | 8400 | 140 | 9576 | 160 |
| ILVE120 | 32 | 60 | 563 | 8520 | 142 | 9713 | 162 |
| 32 | 80 | 750 | 11280 | 141 | 12859 | 161 |
| 32 | 100 | 938 | 14000 | 140 | 15960 | 160 |
Asymmetric Extensive (AE)
Asymmetric Extensive Wide (A3)
Symmetric Extensive (SE)
Asymmetric Extensive Frontal (A1)
*Show 4 recommended lighting distributions. Refer to the 18 typologies.
